Red V-Raptor XL 8K VV

Weekend Price: $1,200 • 1 Week Price: $3,600

Description

1,200.00

Per Day

“Looking for a longer-term rental? Please Contact Us for a custom quote.”

RESOLUTION: 8K (8192 x 4320)
MAX FRAME RATE: 8K 120
BATTERY TYPE: V-mount
SENSOR: 40.96 x 21.6 mm (VV) CMOS
OUTPUT OPTION: 3 x BNC (12G-SDI) Output 1 x BNC (3G-SDI) Output 1 x Proprietary Output
CODEC: REDCODE raw, Apple ProRes
MOUNT: PL
MEDIA: Single Slot: CFexpress Type B
INTERNAL HD: Integrated Electronic ND 2-7 stops
MANUFACTURER: RED
WEIGHT: 7.99 lbs

Key Features:

35.4MP 8K VV Sensor, up to 8K120 Video
Purpose-Built Unified Body
Interchangeable PL Mount Included
Integrated Electronic ND Filters
Powerful & Versatile 12/24V Outputs
Industry-Standard Input/Output Array
REDCODE Raw, Apple ProRes Recording
Wireless Timecode & Genlock Functions
V-Mount Battery Plate

V-RAPTOR XL 8K VV: Advanced Multi-Format Capture

The V-mount V-RAPTOR XL 8K VV Camera from RED DIGITAL CINEMA offers up to 8K VV multiformat video capture, REDCODE raw and Apple ProRes recording, and 1080p streaming in a streamlined form featuring an array of interfaces suitable for high-end crew use. This follow-up to the V-RAPTOR incorporates internal ND filters and an interchangeable lens mount, and it includes an ARRI PL mount. Its industry-standard interface incorporates three 12G/6G/3G-SDI outputs, both 12 and 24V power outputs, timecode and genlock ports, and a V-mount battery plate.

Multi-Format 8KVV + 6K S35 Sensor

This high-end, all-in-one solution offers both 8K VV and 6K S35 sensor selections, enabling creators to tailor their capture to the needs of each of their projects.
A bevy of frame rates range up to 8K120 and 6K160, ii includes multiple anamorphic options, and it offers data rates up to 800 MB/s when using RED or other approved CFexpress cards.

Internal ND Filters

Motorized clear and 2 to 7-stop ND filters with 1/3, 1/4, and 1-stop increments provide precision exposure control.
The internal NDs are easily controlled via the side push buttons or wirelessly using the iOS/Android RED Control app.

Advanced Cooling

The V-RAPTOR XL’s advanced cooling system uses dedicated fans to separately reduce the temperature of auxiliary power components and camera components while a heat exchanger maintains a precise sensor temperature.
Together, these cooling functions reduce noise while recording, create a more robust system, and produce less black shading.

Image Gallery:

Additional Details

RESOLUTION: 8K (8192 x 4320)
CODEC: REDCODE raw, Apple ProRes
MAXIMUM FRAME RATE: 8K 120
MOUNT: PL
BATTERY TYPE: V-mount
MEDIA: Single Slot: CFexpress Type B
SENSOR: 40.96 x 21.6 mm (VV) CMOS
INTERNAL HD: Integrated Electronic ND 2-7 stops
OUTPUT OPTION: 3 x BNC (12G-SDI) Output 1 x BNC (3G-SDI) Output 1 x Proprietary Output
WEIGHT: 7.99 lbs
MANUFACTURER: RED
